Special feature
  • Multi Input : Thermocouple 5, Thermoscope resistor 1, DC voltage 2, Direct current 1, Sensor input of 9 kinds of humidity sensors, etc.
  • Output : relay outputĀ  3(Standard), Electric current Output 2(Option), SSR Output(Option)
  • RS485, RS232, RS422 transmission(Option) : free provision of a monitoring program(use of 20 ea) for demonstration
  • Output current limitation: A function to limit the top/bottom of output current value
  • Simple operation : Simplification of each function to easily set it by hiding and minimizing complicated functions
  • Control method : PID control(setting up direction/inverse), ON/OFF control(setting up direction/inverse)
  • Heater disconnection alarm and sensor disconnection alarm
  • 10 kinds of alarms
  • ON/OFF timer output function
